The all-new Tangent Theta TT735P, 7-35x56mm Professional Series Riflescope is the latest release from Tangent Theta that offers the extreme long range shooter unfailing ruggedness, mechanical precision and unsurpassed image quality.
The Tangent Theta TT735P is a purpose built tactical riflescope designed to withstand harsh use in adverse conditions in order to accomplish the mission.
This 35x rifle optic delivers better positive target identification at distance with increased magnification, features the ability to parallax down 10 meters and is 24mm shorter than Tangent Theta 25x models (TT525P), all benefits to the Extreme Long Range and Precision Rifle Series marksman. The TT735P includes Tangent Theta’s legendary elevation and windage turrets that deliver precise tactile response and feature a truly TOOL-LESS RE-ZERO® procedure and lockable diopters.
Through the use of high quality glass and lens coating, the TT735P provides exceptional image quality and light transmission as well as providing innovative features such as the Tangent Theta Tool-Less Re-zeroing System, Articulating Lens Covers, and Integrated Parallax and Illumination Knob. The large internal adjustment range allows the scope to be effectively used on a wide variety of platforms while the 0.1 mrad clicks makes trajectory corrections a snap when used in combination with Tangent Theta (Horus Tremor3, Gen 3 XR or JTAC).
The Tool-Less Re-zeroing System eliminates the need for wrenches and other tools, truly a tool-less system to re-zero the elevation and windage knobs.
The Tenebraex Articulating Lens Covers can be rotated 360° and set to open according to the user's preferences, flipped back 270° to reduce the profile of the scope and improve visibility of the knobs while in a shooting position.
The Integrated Illumination/Parallax Adjustment provides more ring mounting space. The pull out illumination knob has 11 intensity settings with a power-down between each numbered setting and a six-hour auto shut off.
28 mrad Double Turn knobs are standard on the Tangent Theta TT735P; 7-35X56 and provide 0.1 mrad click per hash mark, as well as the MTC (more tactile click) option. The double turn knob also features a revolution indicator that provides the operator a visual and tactile reference of location in the travel range. The revolution indicator automatically extends when transitioning into the second revolution.
Tangent Theta tactical scopes are built in Canada and are specifically designed and function-tested for long lifecycles in the harshest of environmental conditions. The company has assembled a highly experienced development team consisting of optical designers, mechanical designers, engineers and international-class long range marksmen. The end result is a series of superior scopes that are beyond reproach in all aspects of design, utility, and service performance.
Tangent Ø Theta 7-35x56mm Manual ...
What is Mil and how to transition
As for scope rings for the 7-35x56mm with 36mm tube, CORETAC SOLUTIONS suggests the following mounting systems depending on your requirement:
- SPUHR Unimount SP-6XXX series
- AREA 419 Tactical One-Piece or Matched Scope Rings
The SPUHR Unimount SP-6XXX series and AREA 419 Tactical One-Piece or Matched mounting systems are special order. For placing special order, please email us at info@coretacsolutions.com
| Product Features: |
- 56mm objective lens
- 36mm main tube
- Eleven reticle illumination settings
- Side parallax adjustment and focus down to 10 meters
- Tool-less re-zero feature (US Patent # 10,591,253)
- Non-translating knobs with elevation zero-stop
- Double-turn elevation with rev indicator
- 7-35x magnification range
- Lockable rapid adjusting diopter
- First Focal Plane Illuminated Reticle
- Reticles
- Mil Based -- Horus Vision Tremor3 Mil/Mil Reticles
- Mil Based -- Gen 3 XR Mil/Mil Reticles
- Mil Based --JTAC Reticle Mil/Mil Reticles
Magnification 7x-35x Length 405mm Width 103mm Height 86mm Weight 1230g Tube diameter 36mm Objective bell diameter 65mm Objective lens diameter 56mm nominal Eyepiece diameter 48mm Reticle options Gen 3XR Fine, JTAC, Tremor3 Field of View @ 7x 3.1 degrees (5.41m @ 100m) Field of View @ 35x 0.62 degrees (1.08m @ 100m) Diopter range -3 to +2.5 Eye relief 90mm Exit pupil @ 5x 8mm Exit pupil @ 25x 1.6mm Re-zero mechanism tool-less re-zero (patent pending) Total Adjustment Range Elevation 30 mrad (103 MoA) Windage +/- 14 mrad (+/- 48 MoA) Working Adjustment Range Elevation 28 mrad (96 MoA ) Windage +/- 6 mrad (+/- 20 MoA) Adjustment resolution 0.1 mrad or 1/4 MoA Parallax adjustment range 10m to infinity Crosshair illumination LED, 11 settings Battery type DL2032 3v lithium Exterior finish Type II Anodized, matte Environmental Waterproof: 4 hours @ 10 meters Shockproof: 700g’s @ 10,000 cycles Standard accessories: Tenebraex® lens covers & ARD
