NEW for 2024, the ELCAN SpecterDR 1x/4x comes equipped with integrated Picatinny rails, ambidextrous magnification throw levers, improved battery covers, and hard-wearing CERAKOTE® performance finishes in Black or Flat Dark Earth (FDE).
ELCAN SpecterDR represents a revolution in optical sight design. The world's first truly dual field of view combat optical sight that combines the best of close and precision fire ranged combat features. SpecterDR switches instantly from 4x magnified sight to a 1x CQB sight at the throw of a lever. Unlike zoom sights, the SpecterDR offers an optimized optical path and identical eye relief in both 4x and 1x modes. Depending on the situation, the user may adjust the sight to illuminate the entire crosshair or just a 1.5 MoA dot in the center. In 1x mode, the SpecterDR has by far the largest field of view in the industry. In 4x mode the SpecterDR offers a generous field of view, long eye relief, and ELCAN's legendary crystal clear image. Situational awareness in both magnifications is improved with ultra-wide viewing angles and unmatched viewing in low light conditions. SpecterDR is half the weight and twice the capability of carrying two scopes, without compromise to mission effectiveness or reliability.
The SpecterDR offers the best single solution for both CQB and Long Range engagements and is designed to withstand the rigors of modern professional use.
ELCAN SpecterDR has been chosen and deployed to US Special Operations and Navy Seals units.
SpecterDR 1x/4x Spec Sheet ...
SpecterDR 1x/4x Manual ...
ELCAN is proud of its reputation as a one-stop solution provider to defense and homeland security customers. In addition to the Specter and Phantom products shown in this section, ELCAN is also able to design and manufacture custom rifle sights and “next-generation” fire control systems for their military and commercial customers. Their experience in merging the best minds with the latest technologies makes ELCAN the best mission partner for developing advanced, cost-effective sighting systems.
| Product Features: |
| SpecterDR 1x/4x Specifications | |
|---|---|
| Magnification | 1x/4x |
| Length | 153mm nominal |
| Width | 71mm nominal |
| Height | 72mm nominal |
| Weight | 598g nominal |
| Reticle | Dual-thickness range finding crosshair with user-selectable red dot |
| Ballistic Correction | 200 to 600m for 5.56 NATO (in reticle) |
| Illumination Source | Battery-powered LED |
| Crosshair Illumination | 5 settings, night vision compatible |
| Red Dot Illumination | 5 settings, night vision compatible |
| Eye Relief | 70mm |
| Field of View | 26 deg @ 1x, 6.5 deg @ 4x |
| FoV @ 1x | 46.2 m @ 100 m (138.4 ft @ 100 yds) |
| FoV @ 4x | 11.4 m @ 100 m (34.2 ft @ 100 yds) |
| Coaxial Alignment | <1.5 MoA between fields |
| Entrance Pupil | 32mm |
| Exit Pupil | 8mm |
| Fixed Focus Range | 20m to infinity |
| Battery Type | CL 1/3N (3v Lithium) |
| Battery Life | 300 hours min., 2000 hours average |
| Exterior Finish | Anodized aluminum, dark green color |
| Adjustment Resolution | 0.5 minute of angle |
| Adjustment Range | 120 minutes of angle |
| Base requirement | Mil-Std-1913 "Picatinny Rail" |
| Attachment | ARMS Levers |
| Environmental: - Waterproof: - Shockproof: |
66 ft for 2 hours min 450 g's |
| Available Options | Anti-Reflection Device |
