This is a high quality, strong and light weight Recoil Lug for all short and long action Savage centerfire models based on the 10, 110, 11, 111, 12, 14, 114, 16, 116 and the Stevens 200. The Lumley Arms Titanium Recoil Lug is also compatible with AccuStock and AccuFit.
Simply put - Lumley Arms titanium lugs are flatter, thicker and stiffer than the factory lug and provide a more secure fit into the aluminum bedding spine of the Savage AccuStock. Even with Savage's floating bolt head design and 3D bedding system, Lumley lugs maximize the accuracy potential of these inherently accurate actions whilst also achieving an overall reduction in weight when compared to the mass-produced factory lug. CNC machined from Ti6Al4V aerospace titanium alloy with both faces and then precision ground 100% parallel to one another. Lumley design also includes features enabling alignment to the action by indexing the included custom fastener to the existing 6 o'clock slot in the face of the Savage action, or by allowing the lug to be pinned by utilizing the two radial 1/16" diameter holes. Some gunsmithing required for both these methods. They have designed in a radii on both of the bottom edges of the lug for when the barreled-action will be epoxy bedded into a stock.
Fitting Guide:
Installation and fitting is required and recommended to be done by a qualified and professional Gunsmith.
Always ensure the rifle is unloaded and that the bolt has been removed prior to commencing. Minimum tools required are headspace gauges, a barrel vice and a barrel nut wrench. Lumley design enables the titanium lug to be fitted using three popular methods outlined below, head spacing is required after fitting regardless of which method is employed. If in doubt, we highly recommend a gunsmith undertake the work.
(1) Fitting without using either the indexing fastener or radial pins: Their titanium lug can be installed in the same manner as the 2019+ Savage factory recoil lug which is the same configuration and does not have a dimple. This is a drop-in fit to the AccuStock and 'Accufit' stocks. Aligning the lug to the receiver can be done in a number of ways, a recoil lug alignment tool (for lugs with straight sides) is both inexpensive and straightforward.
(2) Fitting using the indexing fastener: This will require a small relief cut made by measuring approximately 0.047" (1.19mm) deep x 0.087" (2.21mm) long immediately behind the recoil lug into the aluminum spine of the stock to accommodate the cap head of the (included) 2.5 x 0.8mm threaded T8 torx screw. This is a basic one minute task with a dremel tool and small grinding bit (alternatively this relief cut can be made using a vertical drill press or milling machine if either machines are available). The cap head of the included torx screw is custom made to be a snug fit into the mating slot of the Savage action, and for this reason we don't recommend using a different fastener.
(3) Fitting using the two radial pins: this is a more permanent solution designed primarily for when barrels are going to be switched often, it requires access to a vertical milling machine, additional fixtures and tooling. Lumley includes two 1/16" dowel pins with a splined retaining head on one end. These pins are designed to be cut to length to suit the depth of the corresponding holes to be drilled into the action face, or alternatively any length 1/16" diameter dowel pins can be used. The drawing for drilling these two radial pin holes is detailed in the image gallery.
Advantages of Lumley Arms Savage Titanium Recoil Lug:
- Strong and light weight
- High quality material and construction
| Product Features: |
- Lumley Arms Savage Titanium Recoil Lug
- Compatible with Savage models 10, 110, 11, 111, 12, 14, 114, 16, 116 and Stevens 200
- Material: Grade 5 Titanium alloy (Ti6Al4V)
- Thickness: ~0.181" (~4.6mm)
- Sizes: Available for both standard shank and large shank Savage barrels
- Construction: CNC machined with both faces precision ground
- Barrel Nut: Compatible with all known factory and aftermarket options
- Center Pin: Optional to install, drilled and threaded for our custom M2.5 x 0.8mm T8 torx head fastener
- Radial Pin: Optional to install, drilled for our custom 1/16" (1.58mm) splined head dowel pins
- Weight (Standard Shank): 10.7g (0.377 oz)
- Weight (Large Shank): 9.7g (0.342 oz)
- Made in Australia by Lumley Arms INC.
